l 抗紫外線，柔軟，阻燃
l 環保標準：RoHS
l 標準顏色：黃、白（其它顏色可定做）
性能 | RSFR | AMS | DIN | HNF |
拉伸強度 | ≥10.3 MPa | ≥10.3 MPa | ≥10.3 MPa | ≥10.3 MPa |
斷裂伸長率 | ≥200% | ≥200% | ≥200% | ≥200% |
熱老化后拉伸強度 | ≥6.9 MPa | ≥6.9 MPa | ≥6.9 MPa | ≥6.9 MPa |
熱老化后斷裂伸長率 | ≥100% | ≥100% | ≥100% | ≥100% |
阻燃性 | VW-1 | VW-1 | S3級 | I2，F2 |
熱沖擊 | 無裂紋、無滴落 | 無裂紋、無滴落 | 無裂紋、無滴落 | 無裂紋、無滴落 |
冷彎柔性 | 無裂紋 | 無裂紋 | 無裂紋 | 無裂紋 |
吸水率 | ＜0.5% | ＜0.5% | ＜1.0% | ＜1.0% |
擊穿強度 | ≥19.7 MV/m | ≥19.7 MV/m | ≥19.7 MV/m | ≥19.7 MV/m |
體積電阻率 | ≥1014 Ω·cm | ≥1014 Ω·cm | ≥1014 Ω·cm | ≥1014 Ω·cm |
注釋：試驗方法與RSFR/AMS/DIN/HNF標識管對應的方法一致。
序號 | 訂貨編碼 | 包裝數量 (片/卷) | 標識 高度 (mm) | 標識 長度 (mm) | 打印范圍 (mm) | 適用范圍 (mm) | |
高度 | 長度 | ||||||
1 | RSFR-4H-10.4-45-2K-W-B-P0-* | 2000 | 10.4 | 45 | 6.4 | 25 | 5.08~12.7 |
2 | RSFR-4H-10.4-53-2K-W-B-P0-* | 2000 | 10.4 | 53 | 6.4 | 33 | 5.08~12.7 |
3 | RSFR-4H-10.4-64-2K-W-B-P0-* | 2000 | 10.4 | 64 | 6.4 | 44 | 5.08~12.7 |
4 | RSFR-6H-10.4-76-2K-W-B-P0-* | 2000 | 10.4 | 76 | 6.4 | 56 | 5.08~12.7 |
5 | RSFR-6H-10.4-90-2K-W-B-P0-* | 2000 | 10.4 | 90 | 6.4 | 70 | 5.08~12.7 |
6 | RSFR-4H-12.0-102-2K-W-B-P0-* | 2000 | 12.0 | 102 | 8.0 | 82 | 12.7~19.1 |
7 | RSFR-4H-15.0-45-1.5K-W-B-P0-* | 1500 | 15.0 | 45 | 11.0 | 25 | 12.7~19.1 |
8 | RSFR-4H-15.0-53-1.5K-W-B-P0-* | 1500 | 15.0 | 53 | 11.0 | 33 | 12.7~19.1 |
9 | RSFR-4H-15.0-64-1.5K-W-B-P0-* | 1500 | 15.0 | 64 | 11.0 | 44 | 12.7~19.1 |
10 | RSFR-6H-15.0-76-1.5K-W-B-P0-* | 1500 | 15.0 | 76 | 11.0 | 56 | 12.7~19.1 |
11 | RSFR-6H-15.0-90-1.5K-W-B-P0-* | 1500 | 15.0 | 90 | 11.0 | 70 | 12.7~19.1 |
12 | RSFR-4H-20.3-45-1K-W-B-P0-* | 1000 | 20.3 | 45 | 16.3 | 25 | 19.1~25.4 |
13 | RSFR-4H-20.3-53-1K-W-B-P0-* | 1000 | 20.3 | 53 | 16.3 | 33 | 19.1~25.4 |
14 | RSFR-4H-20.3-64-1K-W-B-P0-* | 1000 | 20.3 | 64 | 16.3 | 44 | 19.1~25.4 |
15 | RSFR-6H-20.3-76-1K-W-B-P0-* | 1000 | 20.3 | 76 | 16.3 | 56 | 19.1~25.4 |
16 | RSFR-6H-20.3-90-1K-W-B-*-P0-* | 1000 | 20.3 | 90 | 16.3 | 70 | 19.1~25.4 |
17 | RSFR-4H-25.4-45-1K-W-B-*-P0-* | 1000 | 25.4 | 45 | 21.4 | 25 | 25.4 and up |
18 | RSFR-4H-25.4-53-1K-W-B-*-P0-* | 1000 | 25.4 | 53 | 21.4 | 33 | 25.4 and up |
19 | RSFR-4H-25.4-64-1K-W-B-*-P0-* | 1000 | 25.4 | 64 | 21.4 | 44 | 25.4 and up |
20 | RSFR-6H-25.4-76-1K-W-B-*-P0-* | 1000 | 25.4 | 76 | 21.4 | 56 | 25.4 and up |
21 | RSFR-6H-25.4-90-1K-W-B-*-P0-* | 1000 | 25.4 | 90 | 21.4 | 70 | 25.4 and up |
